Features
- Simple and safe connection due to flat contact surfaces and internal chamfer
material
- Copper (EN13600)
Surface
- Tin-plated to protect against corrosion
material
Surface
| Cable type | Description |
|---|---|
 |
Single-strand conductor (Class 1 according to EN 60228) made from bright finish or metal-encased annealed copper |
| PART NO. | Nominal cross-section mm² | Conn. bolts dia. | Dimensions mm | Weight/100 pcs. ~kg | PU/pcs. | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | a | b | d2 | d4 | c1 | c2 | l | |||||
| SR65 | 6 | M5 | 3,0 | 8 | 9,0 | 5,3 | 5 | 4,75 | 6,0 | 17,0 | 0,213 | 25 |
| SR66 | 6 | M6 | 3,0 | 8 | 10,0 | 6,4 | 5 | 6,50 | 6,5 | 19,0 | 0,220 | 25 |
| SR106 | 10 | M6 | 4,0 | 9 | 10,0 | 6,4 | 6 | 7,00 | 6,5 | 19,0 | 0,300 | 25 |
| SR108 | 10 | M8 | 4,0 | 9 | 14,0 | 8,4 | 6 | 8,50 | 9,5 | 22,0 | 0,320 | 25 |
| SR166 | 16 | M6 | 5,0 | 12 | 12,5 | 6,4 | 8 | 6,50 | 7,0 | 23,5 | 0,800 | 25 |
| SR168 | 16 | M8 | 5,0 | 12 | 15,0 | 8,5 | 8 | 9,00 | 9,0 | 26,0 | 0,900 | 25 |
| SR256 | 25 | M6 | 6,2 | 15 | 14,0 | 6,5 | 10 | 7,50 | 7,5 | 30,0 | 1,560 | 25 |
| SR258 | 25 | M8 | 6,2 | 15 | 16,0 | 8,5 | 10 | 10,00 | 10,0 | 32,0 | 1,700 | 25 |
| SR358 | 35 | M8 | 7,0 | 15 | 16,0 | 8,5 | 10 | 10,00 | 10,0 | 32,0 | 1,310 | 25 |
| SR3510 | 35 | M10 | 7,0 | 15 | 18,0 | 10,5 | 10 | 12,00 | 12,0 | 34,0 | 1,570 | 25 |
| SR506 | 50 | M6 | 8,5 | 17 | 17,0 | 6,5 | 12 | 7,50 | 7,5 | 32,0 | 1,850 | 25 |
| SR508 | 50 | M8 | 8,5 | 17 | 17,0 | 8,4 | 12 | 10,00 | 10,0 | 34,0 | 2,000 | 25 |
| SR5010 | 50 | M10 | 8,5 | 17 | 19,0 | 10,5 | 12 | 12,00 | 12,0 | 37,0 | 2,130 | 25 |
