Features
- Improved contact properties due to grooved profile
Material
- Copper (EN13599)
Surface
- Tin-plated to protect against corrosion
Additional information
- * = not standardised
- 0.5 – 6 mm² not UL-tested
Material
Surface
Additional information
| Cable type | Description |
|---|---|
 |
Multi-strand conductor (Class 2 according to EN 60228) made from bright finish or metal-encased annealed copper |
 |
Fine-strand conductor (Class 5 according to EN 60228) made from bright finish or metal-encased annealed copper |
 |
Extra-fine-strand conductor (Class 6 according to EN 60228) made from bright finish or metal-encased annealed copper |
| PART NO. | Nominal cross-section mm² | Nominal size according to DIN | Type | Dimensions mm d1 | Note | Dimensions mm | Weight/100 pcs. ~kg | PU/pcs. | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| a | b | d2 | l1 | l2 | s | h | ||||||||
| ST1705 | 0,5 – 1 | 1 | A | 1,6 | – | 5,0 | — | 1,9 | 17,0 | 10 | 0,8 | — | 0,060 | 100 |
| ST1710 | 1,5 – 2,5 | 2,5 | A | 2,3 | – | 5,0 | — | 1,9 | 17,0 | 10 | 0,8 | — | 0,072 | 100 |
| ST1715 | 4 – 6 | 6 | A | 3,6 | – | 6,0 | — | 2,7 | 20,0 | 11 | 1,0 | — | 0,160 | 100 |
| ST1716 | 10 | — | B | 4,3 | * | 10,0 | 4,3 | — | 24,5 | 11 | 1,0 | 2,0 | 0,270 | 100 |
| ST1717 | 16 | — | B | 5,4 | * | 11,5 | 5,8 | — | 29,5 | 15 | 1,0 | 2,0 | 0,390 | 100 |
| ST1718 | 25 | — | B | 6,8 | * | 13,5 | 6,8 | — | 33,5 | 15 | 1,2 | 2,4 | 0,630 | 100 |
| ST1719 | 35 | — | B | 8,2 | * | 16,0 | 8,0 | — | 40,5 | 20 | 1,5 | 3,2 | 1,170 | 50 |
| ST1720 | 50 | — | B | 9,5 | * | 19,0 | 9,5 | — | 45,0 | 20 | 1,8 | 3,6 | 1,790 | 50 |
| ST1721 | 70 | — | B | 11,2 | * | 24,0 | 11,0 | — | 55,0 | 23 | 2,0 | 4,0 | 2,920 | 50 |
| ST1722 | 95 | — | B | 13,5 | * | 24,0 | 12,5 | — | 55,0 | 23 | 2,5 | 5,0 | 4,300 | 50 |
