Features
- Cross-section-dependent colour-coding
- Temperaturbeständigkeit: bis 105 °C
Material:
- Bronze (CuSnZn)
- Isolierhülse: PA
Surface
- Tin plated to protect against corrosion
Additional information
- 4 – 6 mm² nicht CSA geprüft
Material:
Surface
Additional information
| Cable type | Description |
|---|---|
 |
Fine-strand conductor (Class 5 according to EN 60228) made from bright finish or metal-encased annealed copper |
 |
Extra-fine-strand conductor (Class 6 according to EN 60228) made from bright finish or metal-encased annealed copper |
| PART NO. | Nominal cross-section mm² | Colour | Dimensions mm | Weight/100 pcs. ~kg | PU/pcs. | ||
|---|---|---|---|---|---|---|---|
| l1 | s | Connector dia. | |||||
| 920V | 0,5-1 |
|
24 | 0,38 | 4 | 0,065 | 100 |
| 950V | 4-6 |
|
27 | 0,40 | 5 | 0,150 | 100 |
