Features
- Cross-section-dependent colour-coding
- Special crimping tool required
- Temperature resistance: up to 105 °C
Material
- Copper (ETP)
- Insulation sleeve: PA
Surface
- Tin-plated to protect against corrosion
Material
Surface
| Cable type | Description |
|---|---|
 |
Fine-strand conductor (Class 5 according to EN 60228) made from bright finish or metal-encased annealed copper |
 |
Extra-fine-strand conductor (Class 6 according to EN 60228) made from bright finish or metal-encased annealed copper |
| PART NO. | Nominal cross-section mm² | Colour | Dimensions mm | Weight/100 pcs. ~kg | PU/pcs. | ||
|---|---|---|---|---|---|---|---|
| d1 | l1 | l2 | |||||
| 670WS | 0,5-1 |
|
1,6 | 36 | 15 | 0,12 | 100 |
| 680WS | 1,5-2,5 |
|
2,3 | 36 | 15 | 0,15 | 100 |
| 700WS | 4-6 |
|
3,4 | 41 | 15 | 0,25 | 100 |
