Material
Surface
Assembly instruction
| Cable type | Description |
|---|---|
 |
Multi-strand conductor (Class 2 according to EN 60228) made from bright finish or metal-encased annealed copper. |
 |
Multi-strand sector conductor 90° (Class 2 according to EN 60228) made from bright finish or metal-encased annealed copper |
 |
Multi-strand sector conductor 120° (Class 2 according to EN 60228) made from bright finish or metal-encased annealed copper |
| PART NO. | Nominal cross-section mm² | Colour | Dimensions mm | Weight 100 pcs. ~kg Cu | Weight 100 pcs. ~kg Total | PU/pcs. | |||
|---|---|---|---|---|---|---|---|---|---|
| d1 | d12 | d13 | l10 | ||||||
| 622R | 10 |
|
4,5 | 7,0 | 9,0 | 42 | 0,72 | 0,84 | 25 |
| 623R | 16 |
|
5,5 | 8,5 | 10,5 | 50 | 1,00 | 1,16 | 25 |
| 624R | 25 |
|
7,0 | 10,0 | 12,0 | 57 | 1,41 | 1,63 | 25 |
| 625R | 35 |
|
8,5 | 12,0 | 14,4 | 65 | 2,24 | 2,60 | 25 |
| 626R | 50 |
|
10 | 14,0 | 16,4 | 72 | 3,36 | 3,81 | 25 |
| 627R | 70 |
|
12 | 16,4 | 19,0 | 80 | 4,87 | 5,46 | 25 |
| 628R | 95 |
|
13,5 | 17,8 | 20,8 | 87 | 5,91 | 6,74 | 25 |
